FSCT-35 IP67 outdoor split core current transformer

XH-FSCT-35 IP67 Waterproof Ourdoor Split Core Current Transformer

XH-FSCT-35 IP67 Waterproof current transformer is built with silicone steel core and is potted for outdoor use. In addition, it is designed for easy installation on ground potential conductors.

Specification

Window size : 35 mm

IP rating: IP67

Insulating Medium: Common Insulating Materials

Accuracy: 0.5-1%

Standards: GB20840; IEC 61869

Safety Factor Rating :< 10

Rated Frequency: 50Hz or 60Hz

Secondary Current: 5A or 1A

Secondary Winding Power Frequency Withst: 3kv/1min

Certificates:Waterproof certificate
